DS510 Online Digital pH sensor Probe and Portable pH Meter for Water Quality Monitoring

The digital pH sensor adopts composite electrode technology. The sensor has a built-in temperature sensor, which automatically compensates the temperature. The composite electrode has a longer life and is suitable for online long-term monitoring environments. The sensor adopts RS485 output and Modbus protocol, which can realize networking and system integration without a controller.

āļĢāļēāļĒāļĨāļ°āđ€āļ­āļĩāļĒāļ”āļŠāļīāļ™āļ„āđ‰āļē

Overview:

The DS510 Online Digital pH sensor Probe adopts composite electrode technology. The sensor has a built-in temperature sensor, which automatically compensates for the temperature. The composite electrode has a longer life and is suitable for online long-term monitoring environments. The sensor adopts RS-485 output and Modbus protocol, which can realize networking and system integration without a controller.

Features:

  1. The pH sensor uses compound electrode technology for a long service life.
  2. Not affected by transmission distance, good stability.
  3. Built-in temperature sensor, automatic temperature compensation.
  4. Network integration is possible without a controller.

Technical parameter:

Product NameDigital PH Sensor
ModelDS510
Detection principleComposite electrode
Measurement range0~14
Measurement accuracyÂą1% FS
Resolution0.01
Temperature range0~50°C
Stored temperature0~60°C
Output signalRS-485, MODBUS protocol
Calibration method3 point calibration



Specifications

Waterproof levelIP68
Under pressure1bar
Product materialPOM
Product SizeØ25×198mm
Power informationDC 6~12V,Current <50mA
Cable lengthStandard 5 meters, longer can be customized
