HPT604-GT Fuel Level Sensor for Generator Lower Fuel Tanks
āļĢāļēāļĒāļĨāļ°āđāļāļĩāļĒāļāļŠāļīāļāļāđāļē
āļāļēāļ§āļāđāđāļŦāļĨāļ
This submersible fuel level sensor features high accuracy and high stability though low level in vibrating tanks. Its unique height adjustable design and fully welded structure enable it to work in different sizes of tanks for a long time.
Application :
- Diesel generators
- Fuel tanks or diesel tanks
- Refinery
- Fuel/oil/diesel/petrol level measurement
Advantages
01 Stability and accuracy improved with probe and cable fixed.
02 Able to measure low fuel level in small or vibrating tanks.
03 Suitable for different sizes of tanks.
04 Adopt digital signal processing technology for good disturbance immunity.
05 Custom service provided for specific applications.
Technical Data
| Parameter | HPT604 (type GT) |
| Level Range | 150...2500mm by customize for RS485 Modbus. 500...2500mm by customize for 4-20mA&0-5V |
| Accuracy (Linearity/Hysteresis/Repeatability) | Digital output: Âą0.25%F.S; Analog output: Âą0.25%F.S (2mLR2.5m); Âą0.5%F.S (1mLR<2m); Âą1.0%F.S (0.5mLR<1m); Including non-lin., rep. and hys. Optional; all based on 25degree C |
| Temp Compensation | 0°C~80°C |
| Working Temp | -40-80°C(non-corrosive medium) |
| Medium compatible | Compatible with SUS304 Stainless Steel |
| Output | 4-20mA,0-5V,RS485 Modbus RTU |
| Power Supply | 7-30Vdc,8-30Vdc,3.5-36Vdc |
| Electronic connection | Fixed cable |
| Response time | 10ms |
| Pressure Type | Gauge pressure |
| Water Proof | IP68 |
