5000 Series Non Full Tube Magnetic Flow Meter
5000 series electromagnetic flow meter is a new flow meter that can be used in non-full tubes. It is ideal for water applications or any dirty liquids which is conductive or water based, including water, wastewater, corrosive liquids, pulps, acid, alkaline and salt solutions and other fluids. It features no moving parts without blockage concern and low-pressure drop, with low maintenance are required.
Application :
- Food and beverage
- Water treatment
- Chemical industry
- Electric power
- Paper-making industry
- Pharmaceutical
Advantages
01 Non-full round pipe, rectangular pipe or other special-shaped pipes can be measured
02 OLED display, with white/green/yellow digits optional
03 Module battery with longer working time
04 10 digits for accumulated flow display
05 Forward and reverse two-way flow measurement
06 GSM and GPRS wireless data remote transmission function(optional)
Technical Data
| DN | DN200-DN6000mm,rectangular pipe: width 6m |
| Measurement accuracy | water level Âą2mm; flow rate Âą1.0%; flow rate Âą1.5% |
| Measurement range | flow rate 0.05-10m/s |
| Output | 4-20mA/DC, Pulse output, RS232/RS485 Modbus RTU... |
| Wireless data transmission | GSM and GPRS optional |
| Power supply | 220VAC or 12VDC, 24VDC |
| Medium temperature | 60 |
| Display | Large screen OLED display can display instantaneous flow rate, flow rate, cumulative flow rate, liquid level and other measurement data at the same time |
