TS401 Intelligent Temperature Switch
TS401 is an advanced device designed to monitor and control temperature with high precision and reliability. Unlike traditional temperature switches, TS401 integrates digital technology to offer enhanced functionality, flexibility, and ease of use. It offers dual normally open/normally closed digital switch outputs, digital temperature display, and 4-20mA current output.
Application :
- Hydropower
- Chemical
- City water supply
- Scientific research
- HVAC
- Industrial automation
Advantages
01 High accuracy of 0.5%F.S by utilizing advanced sensor & algorithms
02 Button operation, shortcut button for one-click zero calibration, fast unit switching
03 NOLED display for easy-to-read current temperature, setpoints, and operational status
04 Switch signal damping and signal filtering algorithm
05 On-site programmable temperature sampling frequency & switch thresholds
06 Flexible switching between NPN and PNP
07 180° display information & 300° instrument body rotation
Technical Data
| Temperature Range | -50°C ~ 150°C |
| Power Supply | 12~30VDC, recommended 24V |
| Accuracy | 0.5%F.S |
| Overload Capacity | 150~300% FS |
| Output | 4~20mA + PNP/NPN |
| Pressure Interface | M20x1.5 |
| Electrical Connection | 5-pin aviation plug (M12-5 pins) |
| Measuring Range | 0~1MPa |
| Power Supply | 12~30VDC, recommended 24V |
| Accuracy | 0.5%F.S |
| Overload Capacity | 150~300% FS |
| Output | 4~20mA + PNP/NPN |
| Pressure Interface | M20x1.5 |
| Electrical Connection | 5-pin aviation plug (M12-5 pins) |
