Passive Thermocouple Temperature Sensor
āļĢāļēāļĒāļĨāļ°āđāļāļĩāļĒāļāļŠāļīāļāļāđāļē
āļāļēāļ§āļāđāđāļŦāļĨāļ
Thermocouple temperature sensor is a passive sensor. Based on the thermoelectric effect of temperature measurement principle, it has a wide range of temperature measurement (-40-1800) and stable performance.
Application :
- Thermocouple sensor
- Used in bolier and pipeline etc...
- Temperature measurements of gases and liquids
- Solid surface temperature measurement
Advantages
01 Passive temperature sensor with lowest price.
02 Used for high temperature(max 1800) measurement environment with stable performance.
03 Simple structure and remote transmission of 4-20ma output.
04 Thermocouple sensor manufacturer.
Technical Data
| Product | HTS300 Series |
| Temp Range | -200~600°C (thermal resistor) /-40-1200°C (K type) 0-1800°C. (B type) |
| Accuracy | 0.1%, 0.3%, 0.5% or optional |
| Index Number | B, R, S, K, N, E, J, T(thermocouple) |
| Probe Length | 30mm (default) 100mm, 150mm, 200mm or by customized |
| Diameter | ÎĶ4mm, ÎĶ2mm, ÎĶ3mm, ÎĶ5mm, ÎĶ6mm or customized |
| Cable Length | 1m (standard) or customized |
| Installation | Plug-in installation |
| Cable Material | PVC, Silicone, Teflon, PTFE |
| Connection | 2-wire, 3-wire, 4-wire |
| Terminals | U type, Pin type, Aviation Type |
| Process | Groove Rolling, SMD, etc. |
