Senke Fanless Industrial All In One Computers Panel PC

Senke Fanless Industrial All In One Computers Panel PC

หมวดหมู่ : SENKE , Industrial Panel PC , YPC-WD Bending Cast Aluminum IPC

แบรนด์ :Senke

รายละเอียดสินค้า

MODEL : SK-YPC-WD03

Size: 13.3", 15.6", 18.5", 21.5", 23.6", 27"
Powered by Android or Pentium/Celeron/Intel Core i3/i5/i7
IP65 (front) for water and dust protection
500nits/700nits/1000nits high-brightness touchscreen for optional
10 point PCAP touch and resistive touch
Embedded&VESA mount

SPECIFICATION

Item		/	/	SK-13.3GBH	SK-15.6GBH	SK-18.5GBH	SK-21.5GBH	SK-23.6GBH	SK-27GBH
Mother board	Configuration	Android 3288/3399/3566/3568, Pentium 3556U/3558U/J6412 (Due to size limitations, 7" and 10.1" can only be adapted to individual small motherboards)
	Memory	2G/4G/8G DDR3
	Storage	64G/128G/256G SSD, 500G/1TB HDD
	Upgrade 1	Intel®Core i3-7th/8th
	Upgrade 2	Intel®Core i5-7th/8th
	Upgrade 3	Intel®Core i5-10th
Interface	Wifi,3/4G module	802.11b/g/n (optional), Support 3g/4g/5g (optional),2.4GHz (Optional)
	HDMI	1*HDMI output
	USB	4*USB 3.0
	Network	1RJ45/2RJ45 with 1000 Base-T
	Com	2* COM(RS232), can changed to RS485 or add more 2 to 4 RS232
	Power supply	1*DC lock phoenix terminal, Support 12V or 24V DC
	Expansion interface	1SATA2.0, 1mini PCIe, support M-SATA
	Audio output	1*3.5mm audio
	Other	1*GPIO (Optional)
Display	Size(inch)	7 inch	10.1 inch	13.3 inch	15.6 inch	18.5 inch	21.5 inch	23.6 inch	27 inch
	Screen type	LCD screen with LED backlight
	Resolution	/	/	1920x1080	1920x1080	1920x1080	1920x1080	1920x1080	1920x1080
	Size(mm)(W)*(H)	/	/	295*166.6	344*194	410*231	477*268.5	521.2*293.2	597.2*336.
	Contrast ratio	/	/	700:1	700:1	700:1	1500:1	1500:1	1500:1
	Brightness	/	/	250cd/m²	250cd/m²	300cd/m²	300cd/m²	300cd/m²	300cd/m²
	screen ratio	/	/	16:09	16:09	16:09	16:09	16:09	16:09
Structure	Front and back cover	Front: Aluminum, back cover: sheet metal
	Craft	Glass panel and aluminum frame, with one-piece sheet metal back cover
	Color	Black
	Heat dissipation	Fan cooling
	Panel indicator light	Power state, hard disk state
	Whole size (mm)	/	/	346.4224.4 45.9	400.4254.4 45.9	462.4286.4 51.1	526.9322.4 51.1	578.9353.9 53.1	663.9402.9 52.1
Touch Panel	Touch point	10 point capacitive touch
	Physical Resolution	4096x4096
	Response time	＜5ms
	Accuracy	＜2.5mm
	Transparency	90%
	Protection	The surface is coated with 1:1 PVC protective film
Others	Working environment	-20°C～55°C；Humidity：10%～90%
	Storage environment	Temperature：-30°C～70°C；Humidity：10%～90%
	Installation ways	Embedded, VESA100*100mm
Accessories	Manual	User Manual, certificate of qualification, warranty card
	Bracket	wall mounted bracket,embedded bracket,desktop bracket (optional)
	Adapter	Power adapter

Senke IPC Industrial Panel Industrial Panel Pc PC Touch All in One Pc Fanless Industrial All In One Computers Panel PC
