GSM 3G 4G LTE Temperature Monitoring Alarm

Product Description

nquiry Onsite Environment with a FREE Call from Your Mobile Phone!
Interval Report Onsite Environment to Your Mobile Phone by SMS!
Remote Reset, Remote Reboot, Automatic Reboot Periodicity!
​High-Low Temperature Voltage with SMS Alert!
Support  Modbus RTU Over TCP for Cloud Monitoring!

The GSM 3G 4G LTE Temperature Monitoring Alarm is special for remotely monitoring onsite temperature, power status through wireless GSM/3G/4G Network. When the temperature, power voltage exceed high threshold or low threshold value, will send SMS alert to upto 10 preset mobile phone immediately.

Just dial from Authorized User number, the GSM 3G 4G LTE Temperature Monitoring Alarm will reject at the first “Ring”, no communication cost, and then return the current temperature,power status or voltage. Moreover, it can report onsite environment interval or daily.

The GSM 3G 4G LTE Temperature Monitoring Alarm can be used for solar power monitoring, DC power voltage monitoring, temperature monitoring, Class Room, Public Room, Waiting Room, Hospital, Stations, Fresh Food Warehouse, Office, Meeting Room, Laboratory, Library and anywhere that need monitoring temperature or control temperature in expected range.

Key Features

• GSM/GPRS/3G/4G network communication, can be operated from anywhere, no distance;

• Multiple applications:temperature,humidity,power supply voltage,analog signal,3 phase power status, single-phase power status, etc.;

• Inbuilt MCU monitoring power supply input voltage value, measure range is 0~36V, no need additional sensor to save cost;

• Up to10 authorized phone numbers, 5 can be used to receive call or SMS,and 5 can be used to call and SMS while alarm occurrence;

• Can set timer report and every x hours automatically send its status/value to the first authorized number;

• Support remotely read historic data via SMS;

• Rechargeablebackup battery inside can last 8 hours;

• Modular structure design, replace a module can upgrade the network from 2G to 3G/4G or 3G to 4G;

• Compatible wall installation and DIN35mm industrial rail installation;

• Support Modbus RTU Over TCP and Modbus TCP, can be connected to cloud platform.

Typical Application Scenarios

It is especially used in classrooms, public places, hospitals, stations, food warehouses, offices, factories, libraries, laboratories, and any other places that require and support monitoring of temperature as well as power failure alarms.
