KCS Mini Peristaltic Pump

Technical Parameters

Motor type : Stepper motor
Flow range : 0.01ml /min - 84ml /min
Noise : 50dB
Power : 20W
Control method : Stepper motor driver
Weight : about 560g
Rated voltage : 24V
Pump tube life : 1000h
Motor life : 6000h
Pump tube size : 3.2mm(ID)×6.4mm(OD)
Number of rotors  : 3
Tube connector : Barbed connector
Pump tube material : BPT

Manual 22. KCS-mini peristaltic pump product manual
