Technical Parameters
Specification | KPHM100-HAB10 | KPHM100-HDB10 | KPHM100-STB10 | KPHM100-HBB10 | KPHM100-HEB10 |
Motor Type | DC brushed motor | DC brushless motor | Stepper motor | DC brushed motor | DC brushless motor |
Flow Rate | 90ml/min | 90ml/min | 0-180ml/min | 90ml/min | 90ml/min |
Noise | 60dB | 60dB | 60dB | 60dB | 60dB |
Power | 6 W | 6 W | 10 W | 6 W | 6 W |
Control Mode | On-off control | On-off control / PWM speed regulation | Stepper driver | On-off control | On-off control / PWM speed regulation |
Weight | About 105g | About 148g | About 235g | About 105g | About 148g |
Rated Voltage | 24V | 24V | 24V | 12V | 12V |
Tube Lifetime | BPT:1000h | BPT:1000h | BPT:1000h | BPT:1000h | BPT:1000h |
Motor Lifetime | 800h | 2000h | 6000h | 800h | 2000h |
Tube material | BPT | BPT | BPT | BPT | BPT |
Tube code & size | B10(10#) : 3mm×5mm | B10(10#) : 3mm×5mm | B10(10#) : 3mm×5mm | B10(10#) : 3mm×5mm | B10(10#) : 3mm×5mm |
Number of rotors | 3 | 3 | 3 | 3 | 3 |
