M180T Data Center Monitor Module

8DI+8AI(16bits)+8DO Data Center Monitor Module Item No.: M180T This Data center monitor module offers a combination of 8CH Digital input(DI), 8CH Digital output(DO), and 8CH 16bit measurement resolution Analog input(AI) for an excellent functionality/price ratio.

Categories : BLIIOT , Automation , Rugged Ethernet I/O

Brands :BLIIOT

Introduction

Specifications

Data Center Monitor Module

This Data center monitor module offers a combination of 8CH Digital input(DI), 8CH Digital output(DO), and 8CH 16bit measurement resolution Analog input(AI) for an excellent functionality/price ratio. The Remote I/O Modbus TCP comes with Ethernet port and RS-485 serial port. The Analog input of this Ethernet Remote I/O used for measuring voltage or current, and Digital input and Digital output used for monitoring environmental in Data Center.

8DI	8DO	8AI	Protocol
Wet/Dry contact	SINK	0-20mA/4-20mA	SNMP V1/V2
High speed pulse	High speed pulse	0-5V/0-10V	Modbus RTU/Modbus TCP
counting	output	16bit resolution	MQTT
