H5100 Digital Display Instrument With Single Loop

Categories : HolyKell , Wireless IoT System

Product description

Download

Digital display instrument with single-loop adopts LED dual-screen display, and can output pressure, liquid level, temperature or flow rate and other data at the same time with pressure or liquid level sensor.

Application :

Use with pressure, level and flow meter
High-precision measurement
Diesel generators
Refinery

Advantages

01 Fully automatic SMD packaging technology, stronger anti-interference ability.
02 The double LED screen outputs pressure, liquid level or flow rate and other measurement data.
03 With wireless sensors, a remote monitoring solution can be realized.
04 Sensor accessories manufacturer, one-stop solution.

Technical Data

Input
Input signals	Current	Voltage Resistance Thermocouple
Input impedance	250Ω	500KΩ
Maximum input current	30mA	6V
Output
Output signals	Current	Voltage
Output load capability	500Ω	250 KΩ (Note: Please replace the module for higher load capacity)
Comprehensive parameter
Accuracy	0.2%FS±1 bit
Setting modal	Panel touch keyparameter setting values locking;store the setting values permanently
Display style	-1999 ~ 9999 display range0 ~ 100% measured value lightness bargraph display;LED display for working state
Working environment	Ambient temperature: 0 ~ 50 ;Relative humidity: 85% RH;Far from strong corrosive gas
Power supply	AC 100 ~ 240V, (50/60HZ);DC 20 ~ 29V
Power	5W
Frame	Standard snap-on
Communication	Standard MODBUS communication protocol;RS-485, communication distance up to 1 km;RS-232, communication distance up to 15 metersNote: While with communication function, the communication converter should be a active one.
