CHS9AM - UV Monitoring Radiometer-UV Meter To Monitor UV Intensity Of UV Lamp

On-Line/Real-time Ultraviolet Monitor, RS485 optional Real-time online monitoring of ultraviolet relative intensity(%), irradiances (mW/ cm²), and accumulative time(hours) display respectively. Easy operation, simple identification, precision reading, and control.

Categories : ApoSun , UV Meter

Brands :ApoSun

Product description

Download

Overview

CHS9AM UV Monitoring Radiometer is an on-line ultra violet fail-safe monitor, especially for UV disinfection lamp, ultraviolet light accelerated aging test machine, water treatment, UV air purifier, air sanitizer, ultra-pure water system etc.

The best partner for UV devices on various occasions & applications:

UV curing and aging
Air sterilization
Sewage treatment, Water disinfection
Semiconductor fabrication
Offset printing
Environmental monitoring
Other industrial process control

Main Features

Advanced MCU for controlling, stable & reliable
Standard panel 1/16, 1/8 din: 48×48mm 48×96mm
5 units (0.56 inches )LED display
Automatically accumulated timing for UV lamp running-time
UV irradiance low alarm
Output industrial standardsignals & Convenient used for embeded system
Easy operation & installation
Lighting intensity attenuate 50% off alarming
RS485 optional
Used in curing, aging, air sterilization, sewage treatment, water treatment, ozone detection, arc monitoring, ultra-pure water system and other industries

UVC Intensity Monitoring System

Best Partner for Air Water Purification
UV Lamp 0-19999 Hours Management

Specification

LED Display Specifications

Model	LED display	Display parameters			Alarm			Dimension
		Intensity relative value	Intensity absolute value	Running time	For UV relative value	For UV absolute value	For running time	Frame	Holing
CHS4AM	4 digits LED	✓	×	✓	✓	×	✓	48×48×85mm	45×45mm
CHS4DM	4 digits LED	×	✓	✓	×	×	✓	48×48×85mm	45×45mm
CHS5AM	5 digits LCD	✓	✓	✓	✓	×	✓	48×94×110mm	45×92mm
CHS9AM	5 digits LED	✓	✓	✓	✓	×	✓	48×94×110mm	45×92mm
