JIRS-OP-500 ORP sensor

Categories : JIRS Sensor , Sensors , PH, ORP Sensor

Brands :JIRS

Product description

Short Description:

The JIRS-OP-500 digital ORP sensor is a composite electrode in which a glass indicating electrode and a reference electrode are combined, which is also known as REDOX redox electrode. The data measured is stable and reliable; besides, it is easy to install.
It is widely used for monitoring ORP in sewage plants, waterworks, water stations, surface water, aquaculture, industry and other fields.

Sensor Specifications

Specification	Details
Size	Diameter 30mm* Length 195 mm
Weight	0.2KG
Main Material	Black polypropylene, Ag/AgCl reference gel
Waterproof Degree	IP68/NEMA6P
Measurement Range	-2000 mV~+2000 mV
Accuracy	±5 mV
Pressure Range	0.6 Mpa
mV Value of Zero Point	86±15mV (25°C) (in the pH7.00 solution with saturated quinhydrone)
Range	Not less than 170mV (25°C) (in the pH4 solution with saturated quinhydrone)
Measurement Temperature	0 to 80 degree
Response Time	No more than 10 seconds (reach to the endpoint 95%) (after stirring)
Cable Length	Standard cable with 6 meters long, extendable
