HC7200 Series Performance Computer

Equipped with Intel® Sky/Kaby/Coffee Lake processors, it supports 4-channel slots to meet different application needs, realizes multi-channel PCI/PCIe expansion, modular design of internal components, and ensures stability with wireless cable connection.

Categories : HWAINTEK , Performance Calculation , HC Series

Brands :HWAINTEK

Product description

Download

Product Features

Intel® 10th Generation Processors with LGA1200
1 x DP, 1 x HDMI, 1 x VGA
2 x DDR4 SO-DIMM sockets support up to 64GB memory
3 x Gigabit LAN(2 x Intel i210-AT and 1 x Intel i219-LM)
1 x RS-485, 1 x RS-232
Compact and Rugged design

Specifications

Product Parameters
System parameters	CPU	Intel® Core i3-10105/i5-10400/i7-10700
	chipset	H420E/H470
	BIOS	AMI 128Mbit UEFI
	memory	2x SODIMM DDR4, MAX 64GB
	storage	2x M.2 M-Key 2280, SATA3.0
External I/O	display	1x DP, MAX 4096 x 2304@60Hz; 1x HDMI, MAX 4096 x 2160@30Hz; 1x VGA, MAX 1920 x 1080@60Hz
	Ethernet	1x LAN, Intel® I219LM; 2x LAN, Intel® I210AT
	COM	1x RS-232; 1x RS232/485
	USB	4x USB3.0; 2x USB2.0
	Audio	1x Line-out, 1x Mic-in, Realtek ALC662
Other	REMOTE	2-pin connector with remote switching capability
Other	RESET	Support long - press restart
Internal Expansion	USB	-
	M.2	1x M.2 E-Key 2230, support Wi-Fi; 1x M.2 B-Key 3052, support 4G/5G
	SIM	1x Micro SIM
System	OS	Windows 10 IoT LTSC, Linux
Power supply	input voltage	24V DC IN, 3PIN Phoenix
Power supply	power consumption	MAX 180W
Mechanical parameters	installation	wall-mounted installation
	dimensions	226 x 220 x 68mm
	net weight	3.0kg
Environ- mental parameters	operating temperature	0~60°C, with 0.7 m/s airflow
	storage temperature	-25°C ~70°C, 60°C @ 95% (non-condensing)
	relative humidity	10 ~ 95% @ 40°C (non-condensing)
	EMC	CE, FCC Class B
