Industrial Cellular Router

Product Description

The Industrial 4G Edge Router is not only an industrial router that provides wireless network access, but also features Modbus data acquisition, Modbus to MQTT protocol conversion, remote monitoring via cloud platform, Edge computing, programmable logic operations, etc.

The R10 industrial router can provide wireless access network, and also can performs Modbus Master to poll meters over RS485/232 or LAN ports, then upload the data to cloud platforms under MQTT format, e.g.: AWS IoT, ThingsBoard. And the R10A industrial router can connect the remote I/O modules either by RS485/232 or Ethernet cable to monitoring data or switch on/off devices, etc.

The 4G Edge router features programmable logic control, timer, event trigger, IP connection alarm functions.

R10 industrial router also can used as Modbus RTU/TCP Slaver, convert Modbus to MQTT protocol, Transmit Transparently (Pass-through), and directly connect to cloud platforms such as AWS, THINGSBOARD etc.

R10 industrial 4G router supports TLS, SSL, X.509 Root certificate to ensure the security of data transmission.

When the industrial router communication fails, the data will be automatically restored and retransmit when communication restored.

Key Features

• Supports 4G wireless Internet access, and APN parameters can be set.

• Intelligent anti-drop line, support online detection, online maintenance, automatic redial, ensure that the device is always online；

• Cloud remote background management, remote upgrade and remote configuration；

• GPS is supported and location data can be published via MQTT；

• Supports VPN protocols such as L2TP, IPSEC, and OPENVPN；

• Support RS485 and RS232 serial port transparent transmission and MODBUS RTU to TCP；

• Complete and robust router function, support a variety of Internet access methods: automatic allocation, specified IP, PPPoE；

• Monitors the online status of network devices connected to the LAN port and reports the status through the platform；

• Support IPTABLES firewall, various network protocols；

• Support WAN port and 4G network connection switch, preferentially use WAN port wired network；

• Supports MODBUS and MQTT protocols, and MQTT supports SSL encryption；

• Alarms are sent by SMS or email；

• Supports one-time timers, periodic timers, and cyclic timers；

• Supports remote upgrade through web pages。

• Dynamic DDNS: Supports peanut shell, 88IP, and dynDNS；

Typical Application Scenarios

Energy & Utilities

• Smart grid

• Pumping stations/tank monitoring

• Oil & gas pipeline monitoring

• Transformer station remote management

• Valve control

• Streetlight energy-saving control systems

Industrial & Automation

• Industrial automation

• Supply chain automation

• Pump station monitoring

• Unmanned equipment rooms

• Control room applications

Smart Cities & Buildings

• Intelligent transportation

• Smart buildings

• Building & real estate monitoring

• Fire protection systems

• Public safety

Environmental & Agricultural

• Weather stations

• River monitoring & flood control

• Agriculture/forestry/water monitoring

• Corrosion protection

• Temperature/water leakage detection

Finance & Retail

• Mobile POS terminals

• Vending machine security

Healthcare

• Digital healthcare

• Remote medical monitoring

Security & Emergency

• BTS (Base Station) monitoring

• Security alarm systems

• Surveillance & monitoring alarm systems

• Wellhead/boat/vehicle tracking

Others

• Remote sensing & surveying

• Petrochemical monitoring

• Automated system integration
