AI518 Series Temperature Controller

AI518 Series Temperature Controller

TC/RTD/analog signal,universal software choose input. 2 degree PID arithmetic with auto-tuning function Optional various control output and 4ï―ž20mA linear output 2 loop alarm,many kinds of alarm type are optional. Rich size,big LED display. RS485 communication,ModBUS-RTU protocol. Industrial level of EMC test and higher reliability.

āļˆāļģāļ™āļ§āļ™
āļĢāļēāļĒāļĨāļ°āđ€āļ­āļĩāļĒāļ”āļŠāļīāļ™āļ„āđ‰āļē

Features:

  • Universal input : Tc , Rtd , analog signal
  • With display , alarm and adjust function
  • Advanced two degrees of freedom PID arithmetic ,
  • optional control output and modularized design
  • High anti-interference ability
  • Can be applied to system temperature control



Model Illustration



Ordering Model

ModelControl outputAnalog outputCommunicationInputAccuracyCode
AI518--SC10Voltage outputNoNoSeries include types of input signal
TC input
RTD input
Standard analog input0ï―ž10V、
4ï―ž20mA、0ï―ž50mV、0ï―ž400ÎĐ
Âą0.5%FSA0480AI01
AI518--RC10Relay outputNoA0480AI01
AI518--KC10SCR outputNoA0540AI01
AI518--DC10Current outputSwitchable analogA0600AI01
AI518--SC18Voltage outputNoRS485A0730AI01
AI518--RC18Relay outputNoA0730AI01
AI518--KC18SCR outputNoA0790AI01
AI518--DC18Current outputSwitchable analogA0850AI01
Noteïžš4-20mA output can switch analog output/PID control output in the menu.The factory is PID control output without neted.



Main Technical Parameter

Parameters of the whole meter

Supply Voltage100ï―ž240V AC/DC
Total currentïžœ30mA220VAC/50Hz
transmit output4ï―ž20mA transmit current,load resistance 600ÎĐmax
Control outputRelay output load capability:3A/250VAC
Alarm outputRelay output load capabilityïžš1A/250VAC
Aux.voltage outputDC 24V30mA
Dielectric strenthAmong power supply terminal,relay contact point, signal input terminals>2000VAC 50Hz/1min
CommunicationRS485 communication interfaceMODBUSRTU Protocal
Panel protect levelIP65
Ambient Temperature0ï―ž50 45ï―ž80RH%
Stock Envirenment-10ï―ž60 25ï―ž85RH%



Input Parameters

S/NInput TypeMeasuring RangeResolutionAccuracyInput resistance
0K type Tc-50ï―ž1200°C1°CÂą0.5%F.SÂą3digitsïžž100KÎĐ
1J type Tc0ï―ž1200°C1°CÂą0.5%F.SÂą3digitsïžž100KÎĐ
2E type Tc0ï―ž850°C1°CÂą0.5%F.SÂą3digitsïžž100KÎĐ
3T type Tc-50ï―ž400°C1°CÂą0.5%F.SÂą3digitsïžž100KÎĐ
4B type Tc600ï―ž1800°C1°CÂą0.5%F.SÂą3digitsïžž100KÎĐ
5R type Tc500ï―ž1600°C1°CÂą0.5%F.SÂą3digitsïžž100KÎĐ
6S type Tc-10ï―ž1600°C1°CÂą0.5%F.SÂą3digitsïžž100KÎĐ
7N type Tc-50ï―ž1200°C1°CÂą0.5%F.SÂą3digitsïžž100KÎĐ
8Pt 100-199.9ï―ž650.0°C0.1°CÂą0.5%F.SÂą3digits0.2mA)
9Cu 50-50.0ï―ž150.0°C0.1°CÂą0.5%F.SÂą3digits0.2mA)
10Cu 100-50.0ï―ž150.0°C0.1°CÂą0.5%F.SÂą3digits0.2mA)
11linear voltage 0ï―ž50mV0ï―ž50mV1digitÂą0.5%F.SÂą3digitsïžž100KÎĐ
12linear current 4ï―ž20mA0ï―ž20mA1digitÂą0.5%F.SÂą3digits<150ÎĐ
13linear voltage 0ï―ž10V0ï―ž10V1digitÂą0.5%F.SÂą3digitsïžž47KÎĐ
14linear resistance 0ï―ž400ÎĐ0ï―ž400ÎĐ1digitÂą0.5%F.SÂą3digitsïžž100KÎĐ
