Rika RK600-08 Data Logger of Automatic Weather Station
āļĢāļēāļĒāļĨāļ°āđāļāļĩāļĒāļāļŠāļīāļāļāđāļē
āļāļēāļ§āļāđāđāļŦāļĨāļ
PRODUCT DESCRIPTION
Rika RK600-08 Data Logger with data acquisition, storage, transmission and management, and other functions, is the core component of automatic weather station, which can connect 32 parameter at the same time, has the settings and color LCD display, can communication with PC via cable or wireless connection, provide communication protocol, convenient for secondary development.
SPECIFICATIONS
| Item | Details |
| LCD | 4.3 color touch screen |
| Storage type | Internal storage or external U_disk is optional |
| Internal storage | 65000 pieces of data can be stored. |
| Data interface | RS232 or RS485(customized) |
| Communication mode (Select communication mode) | 48M |
| Communication protocol | MODBUS-RTU(Open communication protocol, the user can convenient for secondary development) |
| Supply | 12VDC with 100-240VAC adapter, solar power supply system optional |
| Record interval | 1min-240min adjustable |
| Measurement parameters | 32 Max. |
| Power consumption | <4W |
| Operating temperature | -40-+75°C |
| Internal protection | Built-in power isolation protection |
| HMI processor | ARM RISC 528MHz |
| Data cloud platform | Upload data to cloud platform through GPRS module or WiFi module. |
| Relay and alarm output | Customized alarm and relay control output |
