Water conductivity sensor features
Application:
The EC sensor have a wide range of applications, it can be used in ultrapure water, pure water, drinking water, sewage, aquaculture, boiler water, circulating water, river monitoring,industrial water, cooling water,wastewater treatment, electroplating, chemical, pharmaceutical, food, surface water, reverse osmosis, seawater desalination, water treatment, etc.
Conductivity probe specification
RMD Conductivity Sensors Specification ComparisonModel | RMD-ISEC2M12 | RMD-ISEC205 | RMD-ISEP105 |
Measuring range | 0...2000uS/cm | 0...2000uS/cm | 0...2000uS/cm |
Constant | K=1.0 | K=1.0 | K=1.0 |
Accuracy | Âą2%FS | Âą2%FS | Âą2%FS |
Resolution | Âą1uS/cm | Âą1uS/cm | Âą1uS/cm |
Temperature range | 0...60°C | 0...60°C | 0...60°C |
Temp compensation | Automatic | Automatic | Automatic |
Power supply | DC12V,DC24V | DC12V,DC24V | DC12V,DC24V |
Output signal | RS485, 4-20mA | RS485, 4-20mA | RS485, 4-20mA |
Shell material | ABS | ABS | PPS |
Pressure range | 0...4bar | 0...4bar | 0...4bar |
Thread | M39*1.5 | M39*1.5 | 3/4 |
Electrical connection | M12 connector | Pin type | Pin type |
Installation | Flow through type | Flow through type | Immersion type |
Cable length | 5m or customize | 5m or customize | 5m or customize |
Protection grade | IP68 | IP68 | IP68 |
