CBR Series Braking Units

CBR600 Series

CBR600 series energy consumption braking units are mainly used in large inertia loads, four-quadrant loads, fast stops and long time energy feedback occasions. During the braking of the driver, due to the mechanical inertia of the load, the kinetic energy of the motor is converted into electric energy and fed back to the driver, resulting in the DC bus voltage of the driver rising. The energy consumption brake unit converts excess electric energy into resistive thermal energy consumption to prevent excessive bus voltage from damaging the driver. The energy consumption brake unit has over current, over voltage, over temperature, brake resistance short circuit protection, etc. With the parameter setting function, the user can set the braking start and stop voltage. It can meet the need of high port, over driver braking through master and slave parallel.

Product Characteristics

Product Model and Specification

Dimensions of Mounting Holes
