Rika RK500-04 Type-A Optical Dissolved Oxygen (DO) Probe (Economy）
รายละเอียดสินค้า
ดาวน์โหลด
PRODUCT DESCRIPTION
The 500-04 Type-A sensor is a sophisticated and reliable solution engineered for precision monitoring in diverse aquatic environments, designed to meet the rigorous demands of modern farming, freshwater aquaculture, river, and channel management. This versatile device integrates two critical sensorsdissolved oxygen (DO) and temperaturedelivering industry-leading performance across a wide range of applications.
Technical Parameter Table
Technical Parameter 500-04 Type-A Table| Technical Parameter | ||
|---|---|---|
| Type | 500-04 Type-A Economy | |
| Application | Farming, freshwater aquaculture,river,channels etc | |
| Sensor | DO | Temperature |
| Range | 0-20mg/L | 0-60 |
| Accuracy | 0.3 mg/L | ±0.5 |
| Resolution | 0.01mg/L | 0.1 |
| Repeatability | 0.1mg/L | |
| Response time | T90<100S | |
| Stability | Drift <0.3mg/L/year | |
| Material | Fluorescent cap: 316L, other :ABS | |
| Principle | Fluorescent | |
| Temperature compensation | Thermal resistance | |
| Thread | Lower: NPT3/4,Upper:NPT3/4 | |
| Installation method | Pipe or dip (IP68) | |
| Operating temperature | -5 - +60 | |
| Working pressure | 0.6Mpa | |
| Supply | 7-28VDC | |
| Power consumption | <0.2W | |
| Output | RS485 & 4-20mA at the same time | |
| Ingress protection | IP68 | |
| Cable length | 5m default, other length customizable | |
| Weight(probe) | 0.7kg | |
| Storage | -20 - +80°C | |
Rika
Rika Sensor
Sensor
RK500-04
Dissolved Oxygen (DO) Probe
RK500-04 Type-A
Optical Dissolved Oxygen (DO) Probe
