LoRa Water Quality Total Hardness Sensor
PRODUCT FEATURES
- The main purpose is to detect the total hardness of water, with calcium carbonate (CaCO3) as the measurement standard. It also has an automatic temperature compensation function, and the measurement is not affected by changes in water temperature.
- Low impact on the surrounding environment, high accuracy of measurement results, and reliable presentation of water quality hardness data.
- Connected to equipment through aviation connectors, this interface is stable, durable, and easy to install and disassemble.
- Supporting LoRaWAN protocol, stable wireless data transmission can be achieved after connecting to the corresponding collector.
- Suitable for various scenarios that require online automatic continuous detection of water quality hardness, flexible and convenient to use.
- Whether it is industrial wastewater, surface water, drinking water, seawater, or water quality in industrial production processes, it can be accurately detected.
PRODUCT PARAMETERS
| Power Supply | DC12/24V |
| Weight | 150g |
| Measuring Range | 0-1000mg/L(default) |
| Temperature Measurement Range | 0-50,Reaolution Ratio:0.1 (When manually compensating for temperature, it is set to 25 by default.) |
| Measurement Error | Âą5%FS (25) |
| Resolution Ratio | 0-1000mg/L:0.1mg/L |
| Working Conditions | 0~40,<0.1MPa,4~10pH |
| Electrode Usage Cycle | 1~2 years |
| Transmitter Line Length | Default 5m (other lengths can be customized) |
| Frequency | CN470/IN865/EC868/RU864/US915/AU915/ KR920/AS923-1&2&3&4 |
| Mode | OTAA Class A/C |
| Reporting Cycle | 5min (default) |
| Communication Protocol | LoRaWAN, LoRa TDMA Networking |
PRODUCT APPLICATIONS
1.Accurate measurement: Using calcium carbonate (CaCO3) as the measurement standard, accurately detect the total hardness value of water.
2.Intelligent temperature control: equipped with automatic temperature compensation function, the measurement results are not affected by water temperature fluctuations, and the data is stable and reliable.
3.Green and low consumption: It has minimal impact on the surrounding environment, low energy consumption, and meets environmental protection requirements.
4.Stable connection: Using aviation connectors, the connection is stable and durable, and easy to install and disassemble.
5.Wireless remote transmission: Supports LoRaWAN protocol to achieve stable wireless data transmission over long distances, freeing oneself from the constraints of wiring.
6.Widely applicable: Suitable for online automatic continuous detection of industrial wastewater, surface water, drinking water, seawater and other multiple scenarios.
