The Carbon Dioxide (CO2) Temperature and Humidity Sensor is a product of LPWAN (Low Power Wide Area Network).
This product is widely used in the M2M industry and is widely used in the IoT industry chain, such as HVAC and indoor air quality monitoring/industrial process and safety protection monitoring/agricultural and animal husbandry production process monitoring/smart pipe gallery and other safety inspections in various carbon oxide environments.
Product SpecificationsWireless Transmission | |
Communication Protocol | LoRaWAN,LoRa TDMA Networking |
Frequency | CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4 |
Tx Power | 20dBm (915) / 16dBm (868) / 17dBm (470) |
Mode | OTAA/ABP Class A |
Sensors | |
Ammonia (CO2) | Range: 0-5000ppm Accuracy: ±(50ppm+5% reading value) |
Temperature | Range: -40~+80 Accuracy: ±0.3 |
Humidity | Range: 0~99.9 %RH Accuracy: ±2 %RH |
Operation | |
Configuration | NFC Configuration via Mobile App |
Physical Characteristics | |
Power Supply | 12/24VDC |
Operating Temperature | -30°C to 70°C |
Dimensions | 90x85x40 mm |
Installation | Wall Mounting |
