Product Features
01. Powerful waterproof and dustproof performance, can be used in any harsh environment;
02. Flame-retardant ABS thermoplastic polymer material, sheet metal paint spraying process, safer and more corrosion-resistant;
03. Support PT100/PT1000 temperature analog signal input;
04. Built-in 105-10000H high-quality capacitor, longer life;
05. Independent air-cooling heat dissipation design is more efficient and convenient for cleaning and maintenance;
06. 0.1S output 200% curve current protection, larger torque output;
07. Equipped with PID and PLC functions to facilitate the deployment of intelligent control systems;
08. Complete phase loss, voltage, current, motor and drive protection functions;
09. Powerful motor control performance, supporting SVC speed sensorless vector control and V/F control;
10. Thousands of groups of parameter settings, powerful functions;
11. Wide voltage design -15% to +20%, suitable for more occasions;
Technical Details
| Input Voltage | 380V-480V three phase |
| Output Voltage | 0~480V three phase |
| Output Frequency | 0~1200Hz V/F |
| 0~600HZ FVC | |
| Control Technology | V/F , FVC,SVC, Torque Control |
| Overload capability | 150%@rated current 60S 180%@rated current 10S 200%@rated current 1S |
Simple PLC support max 16-steps speed control 5 Digital inputs，support both NPN & PNP 2 Analog inputs, AI 1 support -10V~10V, AI2 support -10V~10V, 0~20mA & PT100/PT1000 temperature sensor 1 analog output support 0~20mA or 0~10V, 1 FM, 1 Relay, 1 DO | |
| Communication | MODBUS RS485, Profinet, Profibus, CANopen, Ethercat, PG |
Model Dimension
| AC Drive Model | Rated Input Current | Rated Output Current | Adapting motor | Motor Power | Dimensions(mm) | Gross Weight(kg) | ||
|---|---|---|---|---|---|---|---|---|
| (A) | (A) | (kW) | (HP) | H (mm) | W(mm) | D (mm) | ||
| KD600/IP65-4T-1.5GB | 5.0/5.8 | 3.8/5.1 | 1.5/2.2 | 1 | 215 | 140 | 160 | 1.88 |
| KD600/IP65-4T-2.2GB | 5.8/10.5 | 5.1/9.0 | 2.2/4.0 | 2 | 1.88 | |||
| KD600/IP65-4T-4.0GB | 10.5/14.6 | 9.0/13.0 | 4.0/5.5 | 3 | 240 | 165 | 176 | 2.8 |
| KD600/IP65-4T-5.5GB | 14.6/20.5 | 13.0/17.0 | 5.5/7.5 | 5 | 2.8 | |||
| KD600/IP65-4T-7.5GB | 20.5/22.0 | 17.0/20.0 | 7.5/9.0 | 7.5 | 275 | 177 | 200 | 3.51 |
| KD600/IP65-4T011GB | 26.0/35.0 | 25.0/32.0 | 11.0/15.0 | 10 | 325 | 205 | 205 | 6.57 |
| KD600/IP65-4T015GB | 35.0/38.5 | 32.0/37.0 | 15.0/18.5 | 15 | 6.57 | |||
| KD600/IP65-4T18GB | 38.5/46.5 | 37.0/45.0 | 18.5/22.0 | 20 | 380 | 250 | 215 | 9 |
| KD600/IP65-4T-22GB | 46.5/62.0 | 45.0/60.0 | 22.0/30.0 | 25 | 9 | |||
| KD600/IP65-4T-30G(B) | 62.0/76.0 | 60.0/75.0 | 30.0/37.0 | 30 | 450 | 300 | 220 | 18.4 |
| KD600/IP65-4T-37G(B) | 76.0/92.0 | 75.0/90.0 | 37.0/45.0 | 40 | 18.4 | |||
| KD600/IP65-4T-45G(B) | 92.0/113.0 | 90.0/110.0 | 45.0/55.0 | 50 | 570 | 370 | 280 | 34.5 |
| KD600/IP65-4T-55G(B) | 113.0/157.0 | 110.0/152.0 | 55.0/75.0 | 75 | 34.5 | |||
| KD600/IP65-4T-75G(B) | 157.0/180.0 | 152.0/176.0 | 75.0/93.0 | 100 | 580 | 370 | 295 | 52 |
| KD600/IP65-4T-93G | 180.0/214.0 | 176.0/210.0 | 93.0/110.0 | 120 | 52.65 | |||
| KD600/IP65-4T-110G | 214.0/256.0 | 210.0/253.0 | 110.0/132.0 | 150 | 705 | 420 | 300 | 73.45 |
| KD600/IP65-4T-132G | 256.0/307.0 | 253.0/304.0 | 132.0/160.0 | 180 | 78 | |||
