HK75 Smart Monocrystalline Differential Pressure Transmitter

Categories : HolyKell , Pressure Sensors

Product description

Download

Differential pressure transmitter adopts single crystal silicon pressure sensor technology and packaging process to measure steam, combustible gas, liquid (standard and corrosive). Innovative "dual compensation" technology can achieve a high precision of 0.075% F.S. The OLED display and Hastelloy housing make reading easier, with a lifespan of up to 10 years.

Application :

Hazardous area
Differential pressure in gases, steams
Level, volume or mass measurements in liquids
Aerospace
Automotive
Medical equipment
HVAC

Advantages

01 Measures Gauge/absolute
02 High accuracy,better reliability and intrinsically safety
03 Supports HART,FF,Profibus PA, Profibus DP protocol
04 Accuracy: ±0.075% (20°C, range rate10:1)
05 Easy installations without need for heat tracing and insulation

Technical Data

Pressure Sensor Specifications

Measuring medium	Gas, steam, liquid
Accuracy	±0.2%, ±0.075%, ±0.1% (including linearity, hysteresis and repeatability from zero)
Stability	±0.1%/3 years
Ambient temperature influence	±0.04%URL/10°C
Influence of static pressure	±0.05%/10MPa
Power supply	10 ~ 36Vdc(24Vdc recommended)
Power influence	±0.001%/10V (10 ~ 36Vdc), which can be negligible
Ambient temperature	-40°C ~85°C
Measuring medium temperature	-40°C~120°C
Storage temperature	-40°C ~105°C
Display	LCD, OLED
Module temperature shown on display	-20°C~70°C (LCD), -40°C~80°C (OLED)
Explosion-proof rating	Exd II CT6, Exia II CT4
IP Rating for Housing	IP67
