HPT703 Micro Differential Pressure Transmitter
HPT703 Micro Differential Pressure Transmitter provides an accurate solution for low pressure sensing with ranges available from 0-250pa to 0-25Kpa. With variable capacitance sensing technology and argon arc welded sensitive components,it's advanced circuit linearity and temperature compensation technology makes better transmitter performance.
Application :
- Environmental contamination control
- Pipe pressure monitoring
- Medical equipment and devices
- Oven pressure boost and ventilation control
- Purification project
- Underground ventilation
Advantages
01 Using ultra-sensitive air pressure sensor, it can be used for 0-25 Pascal air pressure.
02 Built-in digital temperature compensation function that can withstand high and low temperatures, and can withstand extreme differential pressure environments.
03 IP68 waterproof can be used in rain and snow weather.
04 UL94V-0 flame retardant function can be used for flammable and explosive gases.
Technical Data
| Parameter | HPT703 |
| Pressure Range | 0-100Pa, 0-250Pa, 0-1250Pa, 0-7500Pa |
| Safe overload | 200% F.S. |
| Burst Pressure | 400% F.S. |
| Accuracy(Linearity hysteresis repeatability) | 1.0%F.S, 0.5%F.S, 0.25%F.S optional |
| Long Time Stability | 0.2%F.S/Year |
| Working Temp | 18°C~+65°C |
| Storage Temp | -54°C~+82°C |
| Temperature compensation | 5°C~65°C |
| Zero Point Temp Drift | < 0.06%F.S/°C |
| Full Scale Temp Drift | < 0.06%F.S/°C |
| Zero Error | ±0.5%F.S |
| Total Error | ±0.75%F.S |
| Medium compatible | Air or non-corrosive gas |
| Output | 4-20mA, RS485, 0-5, 0-10, 0.5-4.5V |
| Power Supply | 10-30Vdc |
| Electronic connection | PG-9 or PG-13.5 cable locking device or 1/2" wire opening |
| Pressure connect port | 3/16" gas mouth with 1/4" hose |
| Response time | < 1ms |
| Adjustment | Support local zero and span calibration |
| Pressure Type | Differential pressure (Gage pressure) |
| EMC Standard | Approving |
| Weight | 347.5g |
