HPT700H Standard Industry Differential Pressure Transducers

Categories : HolyKell , Pressure Sensors

Product description

Download

HPT700H Standard Industry Differential Pressure Transducers get all the great performance characteristics of the Micro-Machined Silicon Transducers in these 316 stainless steel differential pressure models.

Application :

Process Controls
Tank Level Measurement
Filter Performance Monitoring
Corrosive Fluids and Gas Measurement
Static Pressure Measurement and Control

Advantages

01 Precision Micro-Machined Silicon Core;
02 Explosion Proof and Non-Incendive Available.
03 High Stability, Low Drift.
04 316 Welded Stainless Steel Construction.
05 Premium Temperature Performance.

Technical Data

Pressure Range	10~50KPa,51~100KPa,101~200KPa,201~1000KPa
High port overload	50~500 KPa,500~1000 KPa,10~20 Bar,20~40Bar
Low port overload	30~150KPa,150~300KPa,300~600KPa,600~1000KPa
Max Static Pressure	50 bar,100 bar,150bar,200bar
Accuracy	±0.5%F.S (Typical); ±0.25%F.S (by customized)
Stability	0.1%F.S/Year
Ambient Temp Span	-40°C~85°C
Medium Temp Span	-40°C~85°C / -40°C~125°C(with cooling device)
Temperature compensation	0°C~50°C
Zero Temp Drift	0.02%F.S/°C
Span Temp Drift	0.02%F.S/°C
Medium compatible	Compatible with 316 Stainless Steel
Power Supply	7~30Vdc,8~30Vdc,15~30Vdc,7~30Vdc
Output	4-20mA,0-5V,0-10V,I2C,RS485...
Electronic connection	Fixed cable and water proof IP67 (HPT700-S); Terminal Box DIN43650 IP65 (HPT700-H,HPT700-G)
Pressure connect port	1/4"-18NPT Female, G1/4" Male, G1/2" Male, RG=8/ 10gas mouth optional (by Customized)
Process structure	All-Welded Construction (non-O-rings)
Response time	<10ms
Pressure Type	Differential Pressure (Gauge Type)
Certificate	ExiaIICT6 and CE Certificate
Water Proof	IP65 to IP68 optional by model
