HPT611 Anti Clogging Slurry Level Sensor

Product description

Download

The anti clogging slurry level transmitter is the most effective solution for sewage or waste water with viscous medium level measurement.

Application :

Sewage water level in lift station
Slurry level measurement
Sewage water take level monitoring
Mud water level measurement

Advantages

01 All 316L stainless steel construction for durability
02 Open double flange design
03 Added weight prevents movement of the transmitter
04 Cable withstand over 200 pounds of strain
05 High water-proof protection grade IP68

Technical Data

Range	0~100M H2O optional
Output	4-20mA,0-5V,0-10V,0.5-4.5V,RS485 Modbus RTU
Power supply	7-30Vdc,8-30Vdc,13-30Vdc,5Vdc±5%,3.5-36Vdc
Accuracy	0.25%F.S, 0.5%F.S optional
Working temperature	-40-80°C(non-corrosive medium)
Temp Compensation	0°C~50°C
IP rating	IP68
