HPT605 Submersible Sewage Water Level Transducer

Product description

Download

The submersible sewage water level transducer can be used for measuring in polluted environment for a long time. It can not only automatically conduct atmospheric and temperature compensation, but also reduce the temperature drift.

Application :

Sewage water level measurement
Level measurement in water suction pump
Canal water level monitoring
Municipal sewage level measurement
Sediment water level measure

Advantages

01 A removable large diameter 40mm filter nose
02 Surge protection and polarity protection are available
03 Automatic conduction of atmospheric and temperature compensation
04 Fast response, suitable for noisy or adverse conditions
05 Low-Power output signals

Technical Data

Range	0~1 M...200 M H2O optional 80m max for SDI-12 signal
Output	4-20mA,1-5V,0-5V,0-10V,0.5-4.5V,SDI-12,RS485 Modbus RTU
Power supply	7-30Vdc,8-30Vdc,13-30Vdc,5Vdc±5%,12Vdc,12-30VDC,3.5-36Vdc
IP Rating	IP68
Accuracy	0.25%F.S by customized, 0.5%F.S standard
Working temperature	-40-80(non-corrosive medium)
Temp Compensation	0~80
Zero Temp. Drift	0.2%FS/ (100kPa) ; 0.1%FS/ (>100kPa)
FS Temp. Drift	0.02FS/ (100kPa) ; 0.01%FS/ (>100kPa)
Electronic connection	Fixed cable
Response time	10 ms
Certificate	CE,RoHS
Application	City water,Drainage, Sewage pump station etc
