HPT612 Isolated Type Level Transmitter

Product description

Download

HPT612 Isolated type submersible level transmitter features a LCD/LED display and a submersible water probe. It comes equipped with a 270-pound tensile strength shielded and vented cable.

Application :

Vessel and storage monitor systems
Control of lift and pumping stations
Surface water monitoring
Dewatering

Advantages

01 Imported pressure cell, 0.50% F.S
02 316L stainless steel diaphragm, all welded SUS316L body
03 Custom level ranges from 50cm to 100m
04 IP68 full sealed plastic waterproof design
05 Optional Lifetime Lightning Protection

Technical Data

Product Specifications

Range	0 to 0.5m ... 0 to 100m H2O
Output	4-20mA,0-5V,0-10V,RS485 Modbus RTU
Power supply	7-30Vdc,8-30Vdc,13-30Vdc,3.5-36Vdc
Accuracy	±0.5%F.S (Typical), ±0.25%F.S (by customized)
Working temperature	-40-80(non-corrosive medium)
Temp Compensation	0~50
Local Display	LCD or LED
Certificate	CE, Exia II CT6
