HTS201 Explosion-proof type Temperature Transmitter

Categories : HolyKell , Temperature Sensors

Product description

Download

HTS201 thermocouple (resistance) integrated temperature transmitter. It consists of a thermocouple, a thermal resistance and a temperature transmitter module. It uses a two-wire system with a nonlinear correction circuit to directly measure liquids, gaseous media.

Application :

Petroleum
Chemical
Metallurgy
Electric power
Light industry
Textile
Food and other industries.

Advantages

01 High-precision cold junction compensation circuit with compensation accuracy of ±0.5°C over the full temperature range.
02 Unique nonlinear correction circuit, the output signal is linear with the measured temperature.
03 Internal drift self-calibration system guarantees accuracy over the entire operating temperature range.

Temperature Data

Parameter:	HTS201
Measurement Range (Degree C/ °C):	-50 - 0; -50 - 50; 0 - 80; 0 - 100; 0 - 120; 0 - 150; 0 - 200; 0 - 250; 0 - 300 optional
Installation Type:	Insert type
Probe length:	50 mm or customized
Probe Dimension:	Φ8
Sensor Type:	PT100, Pt1000
Signal Output:	4-20 mA + HART or 4-20 mA +RS485 optional
Signal wires type:	2 to 4 wires
Power supply:	24Vdc
Accuracy:	±0.5%F.S.
Working pressure:	40Bar (standard); 300 Bar (customized)
Long time stability:	0.1%F.S.
Response time:	T=50 2.3S; T=90 5.4S
Electronic proof:	Reverse polarity protection; Overload voltage protection (standard); surge protection (customized)
Environment temp:	-40 - 85 Degree C
Storage temp:	-40 - 125 Degree C
Materials of housing:	316L Stainless Steel
Materials of process:	316L Stainless Steel
Water proof grade:	IP67
Explosion Proof:	Yes
Display Units:	LED Indicator Local Display Temp and Panel with 3 keys for Zero and Span setting
