The HW500 LoRa gateway is a cutting-edge IoT communication device supporting 3G/4G mobile broadband standards like FDD-LTE, TDD-LTE, and WCDMA. Featuring a high-performance 64-bit RISC-V processor and embedded Linux OS, it ensures secure, high-speed data transmission. Its industrial-grade design includes an aluminum alloy casing, wide power input range, and advanced self-check mechanisms for stability. With support for Ethernet, 4G/WiFi switching, Modbus protocol, and GPS functionality, its ideal for various industrial applications.
Application :
- Smart Cities
- Industrial Automation
- Smart Agriculture
- Environmental Monitoring
- Utility Monitoring
Advantages
01 Wide network compatibility, including FDD-LTE, TDD-LTE, WCDMA and other 3G/4G mobile broadband network protocols
02 Industrial-grade design equipped with a high-performance 64-bit RISC-V processor and industrial-grade wireless module
03 Features hardware and software watchdogs, multi-level link detection, and self-check mechanisms for automatic fault recovery and continuous, secure operation
04 Versatile connectivity, wired/4G/WIFI network switching, IEEE802.11b/g/n WiFi support, and an Ethernet RJ45 interface for flexible integration with industrial systems
05 Supports remote networking for point-to-point and point-to-multipoint communication, with compatibility for wireless transparent transmission and Modbus protocol
06 High-precision independent GPS positioning for advanced location-based applications
Technical Data
| Built-in 4G Module Wireless Parameters | |
| Standards and Frequency Bands | LTE-TDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/ B28 LTE-TDD: B38/B39/B40/B41 WCDMA: B1/B2/B4/B5/B6/B8/B19 GSM: B2/B3/B5/B8 |
| Receiving Sensitivity | -99 ~ -108dBm |
| Transmit Power | +23 ~ +33dBm |
| Built-in WiFi Module Wireless Parameters | |
| Standards & Frequency Bandwidth | Supports IEEE802.11b/g/n standard, max data rate 150Mbps |
| Receiving Sensitivity | < -72dBm@54Mbps |
| Transmit Power | +16 ~ +23dBm(11g/b/n) |
| Built-in LoRa Module Wireless Parameters Wireless RF | |
| Modulation | LoRa |
| Frequency Range | 433MHz ~923MHz (optional) |
| Transmission Rate | Spreading factor and bandwidth settings |
| Receiving Sensitivity | -137 ~ -148dBm |
| Transmit Power | +22dBm |
| Power Consumption | |
| Maximum Transmit Current | 110mA (22 dBm) |
| Maximum Receive Current | < 6mA |
| Interface Types | |
| One LAN Ethernet Interface(RJ45 socket), Adapter with built-in electromagnetic isolation protection | |
| Antenna Interface | 1 standard SMA antenna interface (for 3G/4G); 3 standard SMA reserved antenna interfaces(for WiFi, GPS, and LoRa) |
| Power Interface | 10~30V (standard DC12V 2A), with built-in power surge protection |
