Robot Phoenix Mantis830-A6 6-Axis Robot
Mantis series 570-A3 six-axis robot has a rated payload of 3kg. The 6 axis industrial robot is developed for complex applications with multiple degrees of freedom. It has graphical operation functions and is simple to program and use.
āļĢāļēāļĒāļĨāļ°āđāļāļĩāļĒāļāļŠāļīāļāļāđāļē
Features of Mantis830-A6 Six Axis Robot
- Payload is 6kg
- Working radius is 830mm
- 6 axes
- Protection grade IP54
Specification of Mantis830-A6 6-Axis Robot
| Robot Model | Mantis830-A6 | ||
| Load | 6kg | ||
| Working Radius | 830mm | ||
| Number of Axles | 6 | ||
| Motion | Axial Motion | Scope of Work | Maximum Speed |
| A1 Joint: Rotation of the First Mechanical Arm | -175°-+175° | 288°/s | |
| A2 Joint: Swing of the Second Mechanical Arm -123°-+97° | -90°-+126° | 240°/s | |
| A3 Joint: Swing of the Third Mechanical Arm -66°-+201° | -201°-+66° | 415°/s | |
| A4 Joint: Rotation of the Fourth Mechanical Arm | -180°-+180° | 421°/s | |
| A5 Joint: Swing of the Wrist Component -118°-+118° | -120°-+120° | 487.5°/s | |
| A6 Joint: Clamp End Rotation | -360°-+360° | 765°/s | |
| Integrated Signal Source | 12 Signals Are Set at the Wrist | ||
| Integrated Air Supply | 4-way Air (5bar) is Set at Wrist | ||
| Repetitive Positioning Accuracy | 0.02mm | ||
| Robot Installation | Table/Ceiling mounting | ||
| Degree of Protection | IP54 | ||
| Dimensions of Robot Base | 250mmÃ250mm | ||
| Robot Height | 1343.5mm | ||
| Weight | 59kg | ||
