Robot Phoenix Python800-B10 SCARA Robot
Python 800-B10 SCARA Robot is a 4-axis robot with a maximum payload of 10kg. It has superior precision, speed, linearity and verticality performance. It can quickly and accurately complete operations such as gluing, assembly, loading, shifting, packaging and so on.
āļĢāļēāļĒāļĨāļ°āđāļāļĩāļĒāļāļŠāļīāļāļāđāļē
Features of Python800-B10 SCARA Robot
- Payload is 10kg
- Working diameter is 1600mm
- Floor mounting
- Protection grade IP54
Specification of Python800-B10 SCARA Robot
| Robot Model | Python800-B10 | |
| Maximum Operating Speed | Joint 1 and 2 | 9360mm/s |
| Joint 3 | 1600mm/s | |
| Joint 4 | 2600°/s | |
| Repeated Positioning Accuracy | Joint 1 and 2 | Âą0.025mm |
| Joint 3 | Âą0.01mm | |
| Joint 4 | ¹0.01° | |
| Load | Rated | 5kg |
| Maximum | 10kg | |
| Measure | Installation Hole Diameter | 160Ã210mm; 4- Ï12 |
| Z-axis Diameter | 25mm | |
| Weight | 39kg (excluding cable) | |
| Installation Type | Table Installation | |
| Interface | I/O Interface | |
| Ethernet | 2 | |
| USB | 2 | |
| Ethercat | 1 | |
| RS232/RS485 | 1 | |
