Blue green algae sensorprinciple
The online blue green algae sensor adopts the principle of fluorescence method. The fluorescence method is more efficient and faster, with better repeatability, and can be monitored online in real time. Self-cleaning brush can be used to effectively eliminate the influence of the measurement. Suitable for industrial circulating water, condensate, wastewater treatment, surface water stations and other water quality monitoring scenarios.
Blue green algae sensor features
1.Digital sensor, RS485 output, support MODBUS
2.With automatic cleaning brush to eliminate the impact of measurement
3.Eliminate the effects of ambient light on measurements with unique optical and electronic filtering techniques
4.Unaffected by suspended solids in water
Blue green algae sensor technical data
Principle | Fluorescence method |
Measuring range | 0...300,000 cells/mL |
Resolution | 1 cells/mL |
The detection limit | 300 cells/mL |
Linearity | R²>0.999 |
Temperature range | 0 ~ 50°C |
Deepest depth | Underwater 10 meters |
Sensor dimension | φ45*163mm |
Power Supply | DC12V, current <50mA (when there is no cleaning brush) |
Output signal | RS485,MODBUS protocol |
Installation | Submersible type |
Shell material | Stainless steel |
Cable length | 5M (default) |
Self-cleaning brush | Yes |
Protection grade | IP68 |
