Robot Phoenix BAT800-S3 Delta Robot
BAT800-S3 delta robot is a 4-axis parallel robot with a rated payload of 3kg, which has the characteristics of high speed and precision, small footprint and strong rated power. It contributes to a flexible production during high precision and high speed manufacturing lines.
āļĢāļēāļĒāļĨāļ°āđāļāļĩāļĒāļāļŠāļīāļāļāđāļē
Features of BAT800-S3 Delta Robot
- The rated payload is 3kg
- The working space diameter is 800mm
- The repositioning accuracy is 0.08mm
- The maximum speed is 6m/s
- The rated power is 3.4kW
Specification of BAT800-S3 Delta Robot
| Robot Model | BAT800M-S3 |
| Rated Load | 3kg |
| Maximum Load | 12kg |
| Working Space Diameter | 800mm |
| Number of Axles | 4 |
| Repeated Positioning Accuracy | 0.08mm |
| Repeated Positioning Accuracy of four Axis Angle (°) | 0.2° |
| Maximum Speed | 6m/s |
| Power Supply Voltage | three-phase AC380V Âą 10%, 50/60HZ |
| Rated Power | 3.4kW |
| Protection Grade | IP54 |
| Weight | 70kg |
Robot
Delta Robot
BAT800-S3 Delta Robot
BAT800-S3
Robot Phoenix
Robot Phoenix BAT800-S3 Delta Robot
Robot Phoenix Delta Robot
