Robot Phoenix BAT600M-E3 Delta Robot

BAT600M-E3 delta robot is a 4-axis parallel robot with a rated payload of 3kg as well as a flexible and sensitive delta arm, which has the characteristics of high speed and precision, small footprint and strong rated power. It contributes to a flexible production during high precision and high speed manufacturing lines.

āļĢāļēāļĒāļĨāļ°āđ€āļ­āļĩāļĒāļ”āļŠāļīāļ™āļ„āđ‰āļē

Features of BAT600M-E3 Delta Robot

  • The rated payload is 3kg
  • The working space diameter is 600mm
  • The repositioning accuracy is 0.08mm
  • The maximum speed is 10m/s
    The rated power is 2.7kW

Specification of BAT600M-E3 Delta Robot

Robot ModelBAT600M-E3
Rated Load3kg
Maximum Load12kg
Working Space Diameter600mm
Number of Axles4
Repeated Positioning Accuracy0.08mm
Repeated Positioning Accuracy of four Axis Angle (°)0.05°
Maximum Speed10m/s
Power Supply Voltagesingle-phase AC220V Âą 10%, 50/60HZ
Rated Power2.7kW
Protection GradeIP54
Weight60kg
