ReignPower NL1100D Series AC-DC Switching Power Supply
Product description
Download
GENERAL SPECIFICATIONS
Input
Input range : 180~264VAC / 255~380VDC
Input frequency : 47~63Hz
Max. I/P current / Inrush current (25°C) : 1A/40A@220VAC
Output
Hold-up time : 13ms
Short protection : Autorecovery
Over load protection : Automatic power limited
DETAIL SPECIFICATIONS
100 Watts
| MODEL | O/P Volt Adj. % | Load(Current) | Ripple & Noise | Line REG. | Load REG | Efficiency | O.V.P | ||
| Min. | Rated | Max. | |||||||
| NL1100D-05 | V : +5V ±10% | 0A | 14A | 20A (Peak 30s) | 180mV | ±1% | ±1% | 81% Ref. | 7.13 ~ 7.88V |
| NL1100D-06 | V : +6V ±10% | 0A | 11.6A | 16.6A (Peak 30s) | 180mV | ±1% | ±1% | 81% Ref. | 7.13 ~ 7.88V |
| NL1100D-12 | V : +12V ±10% | 0A | 8.3A | 8.3A | 180mV | ±1% | ±1% | 83% Ref. | 17.1 ~ 18.9V |
| NL1100D-24 | V : +24V ±10% | 0A | 4.1A | 4.1A | 240mV | ±1% | ±1% | 88% Ref. | 31.4 ~ 34.7V |
