ReignPower NL1240D Series AC-DC Switching Power Supply
Product description
Download
GENERAL SPECIFICATIONS
Input
Input range : 180~264VAC / 200~380VDC
Input frequency : 47~63Hz
Max. I/P current / Inrush current (25°C) : 21.4A/40A@220VAC
Output
Hold-up time : 13ms
Short protection : Autorecovery
Over load protection : Automatic power limited
DETAIL SPECIFICATIONS
240 Watts
| MODEL | O/P Volt Adj. % | Load(Current) | Ripple & Noise | Line REG. | Load REG | Efficiency | O.V.P | ||
| Min. | Rated | Max. | |||||||
| NL1240D-12 | V : +12V +10% -8% | 0A | 16.6A | 20A (Peak 30s) | 150mV | ±1% | ±1% | 88% Ref. | 17.1 ~ 18.9V |
| NL1240D-24 | V : +24V ±10% | 0A | 10A | 10A | 240mV | ±1% | ±1% | 90% Ref. | 31.4 ~ 34.7V |
| NL1240D-48 | V : +48V ±10% | 0A | 5A | 5A | 480mV | ±1% | ±1% | 90% Ref. | 64.6 ~ 71.4V |
| NL2240D1 | V1 : +12V +10% V2 : +5V -8% | 0A 0A | 15.4A 3A | 16.6A (Peak 30s) 3A | 150mV 40mV | ±1% ±1% | ±1% ±1% | 88% Ref. | 17.1 ~ 18.9V 5.8 ~ 7.0V |
| NL2240D2 | V1 : +24V ±10% V2 : +5V | 0A 0A | 9.3A 3A | 10A (Peak 30s) 3A | 240mV 40mV | ±1% ±1% | ±1% ±1% | 90% Ref. | 31.4 ~ 34.7V 5.8 ~ 7.0V |
| NL2240D3 | V1 : +24V ±10% V2 : +12V | 0A 0A | 9A 1.7A | 10A (Peak 30s) 2A | 240mV 80mV | ±1% ±1% | ±1% ±1% | 90% Ref. | 31.4 ~ 34.7V 17.1 ~ 18.9V |
| NL2240D4 | V1 : +48V ±10% V2 : +12 | 0A 0A | 4.6A 1.2A | 5A (Peak 30s) 1.2A | 480mV 80mV | ±1% ±1% | ±1% ±1% | 90% Ref. | 64.6 ~ 71.4V 15 ~ 18V |
