ReignPower NL1480D Series AC-DC Switching Power Supply
Product description
Download
GENERAL SPECIFICATIONS
Input
Input range : 180~264VAC / 200~380VDC
Input frequency : 47~63Hz
Max. I/P current / Inrush current (25°C) : 4.85A/40A@220VAC
Output
Hold-up time : 13ms
Short protection : Autorecovery
Over load protection : Automatic power limited
DETAIL SPECIFICATIONS
480 ~ 500 Watts
| MODEL | O/P Volt Adj. % | Load(Current) | Ripple & Noise | Line REG. | Load REG | Efficiency | O.V.P | ||
| Min. | Rated | Max. | |||||||
| NL1480D-24 | V : +24V ±10% | 0A | 20A | 20A | 240mV | ±1% | ±1% | 84% Ref. | 31.4 ~ 34.7V |
| NL1480D-36 | V : +36V ±10% | 0A | 13.3A | 13.3A | 360mV | ±1% | ±1% | 84% Ref. | 47.8 ~ 53.2V |
| NL1500D-72 | V : +72V ±10% | 0A | 6.94A | 6.94A | 720mV | ±1% | ±1% | 88% Ref. | 84 ~ 90V |
| NL2480D1 | V1 : +24V ±10% V2 : +5V | 0A 0A | 19.3A 3A | 20A (Peak 30s) 3A | 240mV 40mV | ±1% ±1% | ±1% ±1% | 82% Ref. | 31.4 ~ 34.7V 5.8 ~ 7.0V |
| NL2480D2 | V1 : +24V ±10% V2 : +12V | 0A 0A | 19A 1.7A | 20A (Peak 30s) 2A | 240mV 80mV | ±1% ±1% | ±1% ±1% | 82% Ref. | 31.4 ~ 34.7V 17.1~ 18.9V |
| NL2500D1 | V1 : +72V ±10% V2 : +5V | 0A 0A | 6.85A 1.3A | 6.85A 1.3A | 720mV 40mV | ±1% ±1% | ±1% ±1% | 88% Ref. | 84 ~ 90V 5.8 ~ 7.0V |
| NL2500D2 | V1 : +72V ±10% V2 : +12V | 0A 0A | 6.65A 1.2A | 6.65A 1.2A | 720mV 80mV | ±1% ±1% | ±1% ±1% | 88% Ref. | 84 ~ 90V 15~ 18V |
