GENERAL SPECIFICATIONS
Input
Input range : 90~132 / 180~264VAC (Selectable), 220-380VDC
Input frequency : 47~63Hz
Max. I/P current / Inrush current (25°C) : 20A/110VAC / 40A@220VAC
Output
Hold-up time : 13ms
Short protection : Autorecovery
Over load protection : Automatic power limited
DETAIL SPECIFICATIONS
500 Watts
| MODEL | O/P Volt Adj. % | Load(Current) | Ripple & Noise | Line REG. | Load REG | Efficiency | O.V.P | ||
| Min. | Rated | Max. | |||||||
| LP1500D-48M | V : +48V ±10% | 0A | 10.4A | 10.4A | 480mV | ±1% | ±2% | 85% Ref. | 64.6 ~ 71.4V |
