GENERAL SPECIFICATIONS
Input
Input range : 180~264VAC/ 200~380VDC
Input frequency : 47~63Hz
Input current (25°C) : 40A/220VAC
Output
Hold-up time : 10ms
Short protection : Autorecovery
Over load protection : Automatic power limited
DETAIL SPECIFICATIONS
1000 Watts
| MODEL | O/P Volt Adj. % | Load(Current) | Ripple & Noise | Line REG. | Load REG | Efficiency | O.V.P | ||
| Min. | Rated | Max. | |||||||
| LP11K0D-12TDA | V : +12V ±10% | 0A | 83.3A | 83.3A | 150mV | ±1% | ±3% | 82% Ref. | 14.0 ~ 17.0V |
ReignPower
Reign
Power
Power Supply
AC-DC Switching Power Supply
LP Series
ReignPower LP1K0D Series AC-DC Switching Power Supply
