GENERAL SPECIFICATIONS
Input
Input range : 90~264VAC / 127~380VDC
Input frequency : 47~63Hz
Inrush current (25°C) : 20A/110VAC / 40A/220VAC
Output
Hold-up time : 16ms
Short protection : Autorecovery
Over load protection : Automatic power limited
Over voltage protection : Optional
DETAIL SPECIFICATIONS
45 Watts
| MODEL | O/P Volt Adj. % | Load(Current) | Ripple & Noise | Line REG. | Load REG | Efficiency | O.V.P | ||
| Min. | Rated | Max. | |||||||
| RP1045D-05F | V1: +5V ±10% | 0A | 9.0A | 9.0A | 50mVp-p | ±1% | ±1% | 69% Min. | 6 ~ 7.5V |
| RP1045D-12F | V1: +12V ±10% | 0A | 3.75A | 3.75A | 100mVp-p | ±1% | ±1% | 80% Min. | 14 ~ 17V |
| RP1045D-24F | V1: +24V ±10% | 0A | 1.875A | 1.875A | 150mVp-p | ±1% | ±1% | 80% Min. | 28 ~ 34V |
| RP1045D-48F | V1: +48V ±10% | 0A | 1.0A | 1.0A | 300mVp-p | ±1% | ±1% | 80% Min. | 55 ~ 67V |
ReignPower
Reign
Power
Power Supply
AC-DC Switching Power Supply
ReignPower RP1045D Series AC - DC Switching Power Supply
RP1045D Series
