GENERAL SPECIFICATIONS
Input
Input range : 90~264VAC / 127~380VDC
Input frequency : 47~63Hz
Inrush current (25°C) : 20A/110VAC / 40A/220VAC
Output
Hold-up time : 16ms
Short protection : Autorecovery
Over load protection : Automatic power limited
Over voltage protection : Optional
DETAIL SPECIFICATIONS
72 Watts
| MODEL | O/P Volt Adj. % | Load(Current) | Ripple & Noise | Line REG. | Load REG | Efficiency | O.V.P | ||
| Min. | Rated | Max. | |||||||
| RP1072D-24F | V1: +24V ±10% | 0A | 3.0A | 3.0A | 150mVp-p | ±1% | ±1% | 80% Min. | 28 ~ 34V |
