GENERAL SPECIFICATIONS
Input
Input range : 90~264VAC / 127~380VDC
Input frequency : 47~63Hz
Max. I/P current / Inrush current (25°C) : 0.52A/40A@110VAC / 0.33A/80A@220VAC
Output
Hold-up time : 13ms
Short protection : Autorecovery
Over load protection : Automatic power limited
DETAIL SPECIFICATIONS
20~25 Watts
| MODEL | O/P Volt Adj. % | Load(Current) | Ripple & Noise | Line REG. | Load REG | Efficiency | O.V.P | ||
| Min. | Rated | Max. | |||||||
| DLP1020D-05S | V : +5V ±10% | 0A | 4A | 4A | 80mV | ±1% | ±1% | 82% Ref. | 7.13 ~ 7.88V |
| DLP1025D-12S | V : +12V ±10% | 0A | 2.1A | 2.1A | 120mV | ±1% | ±1% | 85% Ref. | 17.1 ~ 18.9V |
| DLP1025D-24S | V : +24V ±10% | 0A | 1A | 1A | 240mV | ±1% | ±1% | 86% Ref. | 31.4 ~ 34.7V |
| DLP1025D-48S | V : +48V ±10% | 0A | 0.52A | 0.52A | 480mV | ±1% | ±1% | 86% Ref. | 64.6 ~ 71.4V |
ReignPower
Reign
Power
Power Supply
AC-DC Switching Power Supply
ReignPower DLP1025D Series AC - DC Switching Power Supply
