GENERAL SPECIFICATIONS
Input
Input range : 90~264VAC / 120~380VDC
Input frequency : 47~63Hz
Max. I/P current / Inrush current (25°C) : 1.82A/35A@110VAC / 0.96A/70A@220VAC
Output
Hold-up time : 13ms
Short protection : Autorecovery
Over load protection : Automatic power limited
DETAIL SPECIFICATIONS
90~100 Watts
MODEL | O/P Volt Adj. % | Load(Current) | Ripple & Noise | Line REG. | Load REG | Efficiency | O.V.P | ||
Min. | Rated | Max. | |||||||
DLP1090D-12C | V : +12V ±10% | 0A | 7.5A | 10.0A (3S) | 120mV | ±1% | ±1% | 91% Ref. | 17.1 ~ 18.9V |
DLP1100D-24C | V : +24V ±10% | 0A | 4.2A | 4.2A | 240mV | ±1% | ±1% | 89% Ref. | 31.4 ~ 34.7V |
DLP1100D-48C | V : +48V ±10% | 0A | 2.1A | 2.1A | 480mV | ±1% | ±1% | 91% Ref. | 64.6 ~ 71.4V |
