GENERAL SPECIFICATIONS
Input
Input range : L1, L2 phase input 340~550VAC / 480~720VDC
Input frequency : 47~63Hz
Max. I/P current / Inrush current (25°C) : 1.5A/60A@380VAC
Output
Hold-up time : 13ms
Short protection : Autorecovery
Over load protection : Automatic power limited
DETAIL SPECIFICATIONS
300 Watts
| MODEL | O/P Volt Adj. % | Load(Current) | Ripple & Noise | Line REG. | Load REG | Efficiency | O.V.P | ||
| Min. | Rated | Max. | |||||||
| LTP1300D-24TDA | V : +24V ±10% | 0A | 12.5A | 12.5A | 240mV | ±1% | ±1% | 90% Ref. | 31.4 ~ 34.7V |
| LTP1300D-36TDA | V : +36V ±10% | 0A | 8.3A | 8.3A | 360mV | ±1% | ±1% | 90% Ref. | 47.8 ~ 53.2V |
| LTP1300D-48TDA | V : +48V ±10% | 0A | 6.25A | 6.25A | 480mV | ±1% | ±1% | 90% Ref. | 64.6 ~ 71.4V |
ReignPower
Reign
Power
Power Supply
AC-DC Switching Power Supply
LTP Series
ReignPower LTP1300D Series AC - DC Switching Power Supply
