GENERAL SPECIFICATIONS
Input
Input range : 3 phase input 340~550VAC
Input frequency : 47~63Hz
Max. I/P current / Inrush current (25°C) : 3.3A/60A@380VAC
Power factor : 83% Min./400VAC/ 80% Min./500VAC
Output
Hold-up time : 18ms/400VAC/ 20ms/500VAC
Short protection : Re-power on to recover
Over load protection : Short-circuit protection
DETAIL SPECIFICATIONS
960 Watts
| MODEL | O/P Volt Adj. % | Load(Current) | Ripple & Noise | Line REG. | Load REG | Efficiency | O.V.P | ||
| Min. | Rated | Max. | |||||||
| LTP1960D-24CENDA | V : +24V ±10% | 0A | 40A | 40A | 200mV | ±1% | ±1% | 92% Ref. | 31.4 ~ 34.7V |
| LTP1960D-48CENDA | V : +48V ±10% | 0A | 20A | 20A | 480mV | ±1% | ±1% | 92% Ref. | 64.6 ~ 71.4V |
ReignPower
Reign
Power
Power Supply
AC-DC Switching Power Supply
LTP Series
ReignPower LTP1960D Series AC - DC Switching Power Supply
