GENERAL SPECIFICATIONS
Input
Input range : 90~264VAC / 127~380VDC
Input frequency : 47~440Hz
Inrush current (25 C) : 20A/110VAC / 40A/220VAC
Output
Hold-up time : 16ms
Short protection : Autorecovery
Over load protection : Automatic power limited
DETAIL SPECIFICATIONS
45 Watts
| MODEL | O/P Volt Adj. % | Load(Current) | Ripple & Noise | Line REG. | Load REG | Efficiency | O.V.P | ||
| Min. | Rated | Max. | |||||||
| RP2045D1S | V1:+5V ±10% V2:+12V ---- | 0A 0A | 2A 2.9A | 2A 2.9A | 50mVp-p 100mVp-p | ±1% ±1% | ±1% ±4% | 72% Min. | 6 ~ 7.5V --------- |
| RP2045D2S | V1:+5.15V ±10% V2:+24V ---- | 0A 0A | 2A 1.46A | 2A 1.46A | 50mVp-p 120mVp-p | ±1% ±1% | ±1% ±4% | 73% Min. | 6 ~ 7.5V --------- |
| RP2045D3S | V1:+24V ±10% V2:+24V ---- | 0A 0A | 1.475A 0.4A | 1.475A 0.4A | 120mVp-p 120mVp-p | ±1% ±1% | ±1% ±4% | 75% Min. | 28 ~ 34V --------- |
| RP2045D4S | V1:+15V ±10% V2:-15V ---- | 0A 0A | 2A 1A | 2A 1A | 120mVp-p 120mVp-p | ±1% ±1% | ±1% ±4% | 75% Min. | 17 ~ 22V --------- |
