GENERAL SPECIFICATIONS
Input
Input range : 90~132/180~264VAC (Selectable) / 220~380VDC
Input frequency : 47~63Hz
Inrush current (25 C) : 20A/110VAC / 40A/220VAC
Output
Hold-up time : 16ms
Short protection : Autorecovery
Over load protection : Automatic power limited
DETAIL SPECIFICATIONS
100 Watts
| MODEL | O/P Volt Adj. % | Load(Current) | Ripple & Noise | Line REG. | Load REG | Efficiency | O.V.P | ||
| Min. | Rated | Max. | |||||||
| RP2100D1M | V1: +12V ±10% V2:+5V ---- | 0A 0A | 7.1A 3.0A | 7.1A 3.0A | 120mVp-p 80mVp-p | ±1% ±1% | ±1% ±1% | 72% Min. | 17.1 ~ 18.9V --------- |
| RP2100D2M | V1: +24V ±10% V2:+5V ---- | 0A 0A | 3.53A 3A | 3.53A 3A | 200mVp-p 80mVp-p | ±1% ±1% | ±1% ±4% | 75% Min. | 27.6 ~ 31V --------- |
